TECHNICAL SPECIFICATION
| CLASSIFICATION | Class I Equipment |
| SHOCK PROTECTION | Type B |
| DEGREE OF MOBILITY | Mobile Equipment |
| INGRESS OF LIQUIDS | Ordinary |
| MODE OF OPERATION | Intermittent |
| POWER CONSUMPTION | 380 watts at 220/ 240v 50 Hz. AC. |
| FUSES | Mains 2 x 3.15amp |
| MOTOR | High precision AC/DC series wound, brush gear, class B insulation, specified to BS5000 pt 2, computer wound coil windings Balanced armature and high speed bearings |
| TIMER | Electronic, graduated in 5,10,15,20,30,45 secs, 1 min and all 30 sec intervals up to and including 15, 20, 25 and 30 mins. |
| BRAKE | Automatic |
| SPEED | 11,800 rpm with 24 place rotor |
| RCF | 13,000 g with 24 place rotor |
| NOISE | 62 dB running with 24 place rotor |
| WEIGHT | 8 kg. net (without rotor) |
| ACCELERATION | 0-11,800 rpm in 70 secs, with 24 place rotor |
| DIMENSIONS | 23.5cm height x 27cm deep x 26cm wide |
| CONSTRUCTION | Steel casing, steel lid |
| FINISH | Body Cream white baked enamel Lid Matt black baked enamel |
